Prepayment Gas Meter
This prepayment steel gas meter system is designed for residential stand-alone housing, complexes, commercial, retail as well as factories. The gas meter has a insufficient gas warning function as well as a emergency gas overdraft. It also has a security and anti-tamper function.
CONTACT US FOR QUOTE
Three Phase Split Prepayment Meter
This Three Phase meter is a split PLC meter with keypad. It complies with STS standard and communicates with a CIU (handheld unit) by Mbus or PLC for convenient energy consumption monitoring and credit charging.
It features extensive tamper protection.
It could also be used as a PLC communication meter by changing the communication module on the meter itself. Maximum power level limit of 100 Amps per phase.
CONTACT US FOR QUOTE
Single Phase Integrated Meter
SINGLE PHASE RESIDENTIAL ELECTRICITY METER.
PPH23GT is the HEXING HXE115-KP which is a high quality, low cost single phase prepaid meter. It contains all the critical metering, token decryption, relay disconnection and reverse energy detection functionality. This meter is designed to wall mount along side a distribution board, it has an integrated User Interface and Keypad.
Laison Water Meter
This PREPAID RESIDENTIAL SPLIT TYPE STS AMI WATER METER consists of two parts, a Prepaid Water Meter, which complies to STS standard IEC 32055-41, and a separate keypad Customer Interface Unit (CIU) with RF Wireless Communication and Dot Matrix Type LCD.
In addition, it supports Automated Metering Infrastructure (AMI) functions by way of a Data Concentrator Unit (DCU) that enables remote management and data collection.
CONTACT US FOR QUOTE
BlueNova RacPower Lithium Iron Phosphate 52V-100Ah-5.2k BP Battery
email: sales@bmsdistributors.co.za
PRODUCT FEATURES
compatible with leading inverter manufacturers.
with all other pure sine wave inverters.
GENERAL SPECIFICATIONS
Battery Chemistry: Lithium Iron Phosphate (LiFePO4)
Nominal Voltage: 51.2V Ah
Rating: 100Ah @C3, 25°C
Installed Capacity @Vnom 5 120Wh
Internal Resistance ≤ 50mΩ @1kHz AC
Serial Communication CAN & RS485
VOLTAGE
Operating Voltage Range 40.0V ~ 57.6V
Bulk Voltage (max.) 57.6V ± 0.3V
Float Voltage (recommended) 54.4V ~ 55.2 V
Low-Voltage (min.) 40.0V
CURRENT
Charge Current (max.) 50A continuous | ≤ 30A recommended
Discharge Current (max.) 100A for 30 mins. | ≤ 70A recommended
Self-discharge Rate Residual capacity: ≤ 3% /month | ≤ 15% /year Recover capacity: ≤ 1.5% /month | ≤ 8% /year
ENVIRONMENTAL REQUIREMENTS
Operating Temperature Range @Charge: 0°C ~ +50°C @Discharge: –10°C ~ +50°C
Recommended Operating Environment Temp. range: +15 ~ +35°C | Humidity: 5 ~ 75%RH
Storage Environment (stored ≤ 1 month) Temp. range: –20 ~ +60°C | Humidity: 5 ~ 75%RH
Storage Environment (stored ≥ 3 months) Temp. range: +10 ~ +45°C | Humidity: 5 ~ 75%RH
PHYSICAL ATTRIBUTES
Dimensions – Main enclosure 446mm x 435mm x 153mm (W x D x H) *
Dimensions – Front plate 481mm x 153mm (W x H)
Net Weight 46.0kg (unboxed, no accessories)
Product Features
Product Features:
Product Specifications
| Weight | 2.6 kg |
|---|---|
| Dimensions | 7.7 × 18.1 × 16.7 cm |
| Battery Type: | LiFePO4 (Lithium Iron Phosphate) |
| Usable Capacity: | 280 Wh @C10, 25°C |
| Nominal Voltage: | 13 VDC |
| Operating Voltage Range: | 11.6 VDC – 14.4 VDC |
| Operating Temperature Range: | Charge: 0°C – 45°C, Discharge: -20°C – 65°C |
| Cycle Life @ 100% DoD: | > 2000 cycles (280 Wh @C10, 25°C) |
| Cycle Life @ 80% DoD: | > 3000 cycles (224 Wh @C10, 25°C) |
| Cycle Life @ 50% DoD: | > 5000 cycles (140 Wh @C10, 25°C) |
| Bulk Voltage: | 14.4 VDC |
| Discharge Voltage (min.): | 11.6 V |
| Charge Current (max.): | 20 A continuous |
| Discharge Current (max.): | 20 A continuous 40 A burst (3 seconds) |
| Self-discharge Rate: | < 3% per month |
| Charge & Discharge Efficiency: | 96% – 99% @C1 |
| Environmental Protection: | IP56 |
| Over-current Protection: | 20 A |
| Over-voltage Cut-out: | 15.6 V |
| Under-voltage Cut-out: | 10.0 V |
Omega Digital Inverter Petrol Generator 12V DC 230V – 50Hz OP-2000IC
Description
Well designed and compact for its size. The Omega OP-21000IC Inverter Generator is the perfect solution for those who need both an inverter and a generator. It comes with all the tools needed to get the product started, it just needs oil & petrol before you start it up.
Rated Voltage – 2KW
Engine Displacement – 4 pace petrol engine
Rated Power Output – AC 230V
Capacity – 4 litre fuel tank
Fuel Type – Oil and petrol
Force Air-cooled, 4 stroke, OHV recoil manual start
2 x 230V plug points
Overload protection
Blue Nova MPS Lithium-Iron Phosphate Battery – 13V 218Ah 2.8kWh
Product Features
Technical Specifications
| Colour: | Black |
| Material: | ABS |
| Battery Chemistry: | LiFePO4 (Lithium Iron Phosphate) |
| Usable Capacity: | 2800Wh @C10, 25°C |
| Cycle Life @ 100% / 80% / 50% DoD: | > 2000 cycles (2800Wh @C10, 25°C) / > 3000 cycles (2240Wh @C10, 25°C) / > 5000 cycles (1400Wh @C10, 25°C) |
| Charge Current: | 100A Continuous (max) |
| Discharge Current: | 100A Continuous | 200A Burst (3 seconds) |
| Over-current Protection: | 300A |
| Bulk Voltage: | 14.4V DC |
| Charge and Discharge Efficiency: | 96% – 99% @C1 |
| Discharge Voltage (Min.): | 11.6V |
| Nominal Voltage: | 13V DC |
| Operating Voltage: | 11.6V DC – 14.4V DC |
| Over-voltage Cutout: | 15.6V |
| Self-discharge Rate: | < 3% per month |
| Under-voltage Cutout: | 10.0V |
| Height: | 245mm |
| Width: | 522mm |
| Depth: | 240mm |
| IP Rating: | IP56 |
| Weight: | 27kg |
| Technical Document: |
BlueNova BN13V-11-140Wh MPS LiFePO4 Battery
General Information
Charge / Discharge
Protection
BlueNova BN13V-218-2.8k MPS LiFePO4 Battery
Product Features
Technical Specifications
RS485 / CAN Hub with 8 ports by Growatt
email: sales@bmsdistributors.co.za
Out of Stock !! Expecting Stock arrival. Orders can be placed in advance !!
This is a listing for RS485 / CAN Hub with 8 ports by Growatt
This product is used for connecting 1 battery bank and up to 7 Growatt inverters or charge controllers.
Whatsapp: +27 69 367 0341
295 watt Solar Panel
Description
250 watt Solar Panel
Description
High Efficiency Solar Panel to give you the natural power that you need. A Versatile panel that has all the features to suit your environmentally friendly footprint for the future. This panel can be used in many applications from powering your house when the power grid is off to giving you power in the middle of nowhere on your adventures.
200 watt Solar Panel
Quick Specs:
72 Cell 125mm X 125mm Series, Monocrystalline Solar Panel
180 watt Solar Panel
Description
Rating: 180W
Efficiency: 14.5%
Width: 992mm
Height: 1,250mm
72 Cell Solar Panel
Rigorous quality control meeting highest international standards
High-transmission low-iron tempered glass, strong aluminium frame using UV-resistant silicon.
Aesthetic appearance with excellent efficiency based on innovative photovoltaic technologies.
What’s in the box
1x 180w Cinco Solar Panel
150 watt Solar Panel
Description
Product Features :
High Efficiency Conversion Modules
Robust waterproof design and strong aluminium frame for all weather conditions
Fitted with a blocking diode to make sure there is no reverse current flow from the battery at night
Corrosion-resistant aluminum frame for extended outdoor use, allowing the panels to last for decades
Easy to install and angle adjustable bracket
Panel specifications:
Maximum power: 150W
Open circuit voltage: 21.6V
Short-circuit current: 9.72A
Maximum power voltage: 18V
Maximum power current: 8.72A
Maximum system voltage: DC1000V
Nominal operating temperature: 45 – 85°C
Operating temperature: -40 – 85°C
Dimensions [l x w x h]: 1490 x 670 x 35cm
Weight: 15.2kg
What’s in the box
1 X 150W Solar Panel
120 watt Solar Panel
Description
This 120w solar panel is powerful enough to keep your battery charged over long periods away without starting the generator or plugging in to an external source. Comes with MC4 connectors so they are easily added to a string and protected from the wet weather. MCS certified, fully weather proof and professionally made with high quality components. You will require a charge controller to regulate the flow of energy into the battery.
Specification:
Panel Size 670mm(w) x 1020mm(h) x 35mm(d)
Weight 10kg
Peak Power: 120w
Open Circuit Voltage: 12V
Short Circuit Current: 5.45A
Power Allowance Range: 3%
Max Power Voltage: 12V
Max Power Current: 5.45A
Max System Voltage: 1000VDC
Number of Cells: 44
What’s in the box
1x120W Solar panel
100 Watt Solar Panel
Description
High Efficiency Solar Panel to give you the natural power that you need. A Versatile panel that has all the features to suit your environmentally friendly footprint for the future. This panel can be used in many applications from powering your house when the power grid is off to giving you power in the middle of nowhere on your adventures.
Product Features :
High Efficiency Conversion Modules
Robust waterproof design and strong aluminium frame for all weather conditions
Fitted with a blocking diode to make sure there is no reverse current flow from the battery at night
Corrosion-resistant aluminum frame for extended outdoor use, allowing the panels to last for decades
Easy to install and angle adjustable bracket
Panel specifications:
Maximum power: 100W
Open circuit voltage: 23.15V
Short-circuit current: 5.45A
Maximum power voltage: 18V
Maximum power current: 5.12A
Maximum system voltage: DC1000V
Nominal operating temperature: 45 – 85°C
Operating temperature: -40 – 85°C
Dimensions [l x w x h]: 1055 x 670 x 35cm
Weight: 8kg
KODAK Solar Off-Grid Inverter King with UPS 5kW 48V (OG-PLUS5.48)
*** Alternative Payment Method for Cape Town Customers ***
email: sales@bmsdistributors.co.za
whatsapp: +27 69 367 0341
Product Description:
Shipment is not included for None Cape Town Customers.
In rural or end-of-line locations, the AC grid voltage can fluctuate across a wide range. Voltage that is sufficently far from the nominal 230V can cause applicances to run much less efficiently, or make them unable to function.
Most other inverters that are capable of running in Island Mode simply pass through the variable grid voltage and only produce a smooth 230V supply in the event of a grid failure.
Kodak’s King Off-Grid inverter is perfect for areas where grid electricity is less stable because it produces smooth 230V AC at all times, whether the grid is available or not.
This is great for efficient running of applicances, but crucial for an uninterrupted supply for important loads such as servers or ATMs.
KODAK Solar Off-Grid Inverter VMIII 5kW 48V OG 5.48
*** Alternative Payment Method for Cape Town Customers ***
email: sales@bmsdistributors.co.za
whatsapp: +27 69 367 0341
Product Description:
Shipment is not included for None Cape Town Customers.
Note: The Kodak VMIII inverter has a RS485 port that can be connected to the RS485 port on the Pylontech batteries for BMS communication. Therefore no other control module, such as the ICC, is needed.
ABOUT US
BMS DISTRIBUTORS IS A SALES SPECIALIST COMPANY. WE UTILIZE OUR STRONG RELATIONSHIP WITH TOP MANUFACTURERS & NETWORK OF DISTRIBUTORS TO OFFER THE MOST EXTENSIVE PORTFOLIO OF PRODUCTS. WHETHER YOU NEED THAT SMALLEST COMPONENT, OR LOOKING FOR THAT HARD TO FIND EQUIPMENT OR SPARES, BMS DISTRIBUTORS WILL SECURE IT WHEN YOU NEED IT.
Products
-
Gas Meters, PREPAID METERS
Prepayment Gas Meter
This prepayment steel gas meter system is designed for residential stand-alone housing, complexes, commercial, retail as well as factories. The gas meter has a insufficient gas warning function as well as a emergency gas overdraft. It also has a security and anti-tamper function.
CONTACT US FOR QUOTE
SKU: n/a -
Electricity Meters
Three Phase Split Prepayment Meter
This Three Phase meter is a split PLC meter with keypad. It complies with STS standard and communicates with a CIU (handheld unit) by Mbus or PLC for convenient energy consumption monitoring and credit charging.
It features extensive tamper protection.It could also be used as a PLC communication meter by changing the communication module on the meter itself. Maximum power level limit of 100 Amps per phase.
CONTACT US FOR QUOTE
SKU: n/a -
Electricity Meters, PREPAID METERS
Single Phase Integrated Meter
SINGLE PHASE RESIDENTIAL ELECTRICITY METER.
PPH23GT is the HEXING HXE115-KP which is a high quality, low cost single phase prepaid meter. It contains all the critical metering, token decryption, relay disconnection and reverse energy detection functionality. This meter is designed to wall mount along side a distribution board, it has an integrated User Interface and Keypad.
SKU: n/a -
PREPAID METERS, Water Meters
Laison Water Meter
This PREPAID RESIDENTIAL SPLIT TYPE STS AMI WATER METER consists of two parts, a Prepaid Water Meter, which complies to STS standard IEC 32055-41, and a separate keypad Customer Interface Unit (CIU) with RF Wireless Communication and Dot Matrix Type LCD.
In addition, it supports Automated Metering Infrastructure (AMI) functions by way of a Data Concentrator Unit (DCU) that enables remote management and data collection.
CONTACT US FOR QUOTE
SKU: n/a -
Batteries
BlueNova RacPower Lithium Iron Phosphate 52V-100Ah-5.2k BP Battery
email: sales@bmsdistributors.co.za
PRODUCT FEATURES
- High Performance:
- Power output = 5.2kW (continuous)
- Fully rechargeable in 2 hours.
- Ultra-reliable Lithium Iron Phosphate Technology.
- Robust & Durable:
- Can be discharged to 100% DoD
- Performance cycle life > 6000 cycles.
- Inverter compatibility:
- Serial communication (CAN/RS485)
compatible with leading inverter manufacturers. - Compatible via voltage-based setup
with all other pure sine wave inverters.
- Serial communication (CAN/RS485)
- Waranty: 5 year product warranty
GENERAL SPECIFICATIONS
Battery Chemistry: Lithium Iron Phosphate (LiFePO4)
Nominal Voltage: 51.2V Ah
Rating: 100Ah @C3, 25°C
Installed Capacity @Vnom 5 120Wh
Internal Resistance ≤ 50mΩ @1kHz AC
Serial Communication CAN & RS485
VOLTAGE
Operating Voltage Range 40.0V ~ 57.6V
Bulk Voltage (max.) 57.6V ± 0.3V
Float Voltage (recommended) 54.4V ~ 55.2 V
Low-Voltage (min.) 40.0V
CURRENT
Charge Current (max.) 50A continuous | ≤ 30A recommended
Discharge Current (max.) 100A for 30 mins. | ≤ 70A recommended
Self-discharge Rate Residual capacity: ≤ 3% /month | ≤ 15% /year Recover capacity: ≤ 1.5% /month | ≤ 8% /year
ENVIRONMENTAL REQUIREMENTS
Operating Temperature Range @Charge: 0°C ~ +50°C @Discharge: –10°C ~ +50°C
Recommended Operating Environment Temp. range: +15 ~ +35°C | Humidity: 5 ~ 75%RH
Storage Environment (stored ≤ 1 month) Temp. range: –20 ~ +60°C | Humidity: 5 ~ 75%RH
Storage Environment (stored ≥ 3 months) Temp. range: +10 ~ +45°C | Humidity: 5 ~ 75%RH
PHYSICAL ATTRIBUTES
Dimensions – Main enclosure 446mm x 435mm x 153mm (W x D x H) *
Dimensions – Front plate 481mm x 153mm (W x H)
Net Weight 46.0kg (unboxed, no accessories)
SKU: n/a - High Performance:
-
Batteries
Product Features
Product Features:
- Ultra-safe Lithium Iron Phosphate (LiFePO4) technology.
- Integrated battery management System (BMS).
- Light weight & compact.
- Water & dust resistant (IP56).
- Highly durable ABS enclosure.
- Drop-in lead acid replacement.
- Warranty Period: 3 Years.
Product Specifications
Weight 2.6 kg Dimensions 7.7 × 18.1 × 16.7 cm Battery Type: LiFePO4 (Lithium Iron Phosphate) Usable Capacity: 280 Wh @C10, 25°C Nominal Voltage: 13 VDC Operating Voltage Range: 11.6 VDC – 14.4 VDC Operating Temperature Range: Charge: 0°C – 45°C, Discharge: -20°C – 65°C Cycle Life @ 100% DoD: > 2000 cycles (280 Wh @C10, 25°C) Cycle Life @ 80% DoD: > 3000 cycles (224 Wh @C10, 25°C) Cycle Life @ 50% DoD: > 5000 cycles (140 Wh @C10, 25°C) Bulk Voltage: 14.4 VDC Discharge Voltage (min.): 11.6 V Charge Current (max.): 20 A continuous Discharge Current (max.): 20 A continuous
40 A burst (3 seconds)Self-discharge Rate: < 3% per month Charge & Discharge Efficiency: 96% – 99% @C1 Environmental Protection: IP56 Over-current Protection: 20 A Over-voltage Cut-out: 15.6 V Under-voltage Cut-out: 10.0 V SKU: n/a -
Generators
Omega Digital Inverter Petrol Generator 12V DC 230V – 50Hz OP-2000IC
Description
Well designed and compact for its size. The Omega OP-21000IC Inverter Generator is the perfect solution for those who need both an inverter and a generator. It comes with all the tools needed to get the product started, it just needs oil & petrol before you start it up.
Rated Voltage – 2KW
Engine Displacement – 4 pace petrol engine
Rated Power Output – AC 230V
Capacity – 4 litre fuel tank
Fuel Type – Oil and petrol
Force Air-cooled, 4 stroke, OHV recoil manual start
2 x 230V plug points
Overload protectionSKU: n/a -
Batteries
Blue Nova MPS Lithium-Iron Phosphate Battery – 13V 218Ah 2.8kWh
Product Features
- Ultra-reliable Lithium Iron Phosphate (LiFePO4) technology
- Integrated battery management System (BMS)
- Light weight and compact
- Water & dust resistant (IP56)
- Highly durable ABS enclosure
- Drop-in lead acid replacement
- 3 Year warranty
Technical Specifications
Colour: Black Material: ABS Battery Chemistry: LiFePO4 (Lithium Iron Phosphate) Usable Capacity: 2800Wh @C10, 25°C Cycle Life @ 100% / 80% / 50% DoD: > 2000 cycles (2800Wh @C10, 25°C) / > 3000 cycles (2240Wh @C10, 25°C) / > 5000 cycles (1400Wh @C10, 25°C) Charge Current: 100A Continuous (max) Discharge Current: 100A Continuous | 200A Burst (3 seconds) Over-current Protection: 300A Bulk Voltage: 14.4V DC Charge and Discharge Efficiency: 96% – 99% @C1 Discharge Voltage (Min.): 11.6V Nominal Voltage: 13V DC Operating Voltage: 11.6V DC – 14.4V DC Over-voltage Cutout: 15.6V Self-discharge Rate: < 3% per month Under-voltage Cutout: 10.0V Height: 245mm Width: 522mm Depth: 240mm IP Rating: IP56 Weight: 27kg Technical Document: SKU: n/a -
Batteries
BlueNova BN13V-11-140Wh MPS LiFePO4 Battery
General Information
- Battery Type: LiFePO4 (Lithium Iron Phosphate)
- Usable Capacity: 140Wh @C10, 25°C
- Nominal Voltage: 13VDC
- Operating Voltage Range: 11.6 VDC – 14.4 VDC
- Operating Temperature Range Charge: 0°C – 45°C | Discharge: -20°C – 65°C
- Cycle Life @ 100% DoD: > 2000 cycles (140 Wh @C10, 25°C)
- Cycle Life @ 80% DoD: > 3000 cycles (112 Wh @C10, 25°C)
- Cycle Life @ 50% DoD: > 5000 cycles (70 Wh @C10, 25°C)
- Dimensions (mm): 151 x 99 x 100mm (W x D x H)
- Weight (kg): 1.5 kg
- Warranty Period: 3 Years
- Drop in lead acid replacement in terms of physical size. Please ensure that your charge controller/ inverter are lithium compatible.
Charge / Discharge
- Bulk Voltage: 14.4 VDC
- Float Voltage: 13.8 VDC
- Discharge Voltage (min.): 11.6 V
- Charge Current (max.): 11 A continuous
- Discharge Current (max.): 11 A continuous 20 A burst (2C, 30 seconds)
- Self-discharge Rate: < 3% per month
- Charge & Discharge Efficiency: 96% – 99% @C1
Protection
- Environmental Protection: IP56
- Over-current Protection: 25 A
- Over-voltage Cut-out: 15.6 V
- Under-voltage Cut-out: 10.0 V
Important: All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. BMS Distributors will not be held liable for any product malfunctions as a result of incorrectly installed systems.SKU: n/a -
Batteries
BlueNova BN13V-218-2.8k MPS LiFePO4 Battery
Product Features
- Ultra-safe Lithium Iron Phosphate (LiFePO4) technology.
- Integrated battery management System (BMS).
- Light weight & compact.
- Water & dust resistant (IP56).
- Highly durable ABS enclosure.
- Drop in lead acid replacement in terms of physical size. Please ensure that your charge controller/ inverter are lithium compatible.
Technical Specifications
- Model: BN13-218-2.8k.
- Capacity (Ah): 218.
- Current (V): 13.
- Energy (Wh): 2834.
- Dimensions (mm): 522 x 240 x 245.
- Weight (kg): 27.
- Charge Current (A): 40.
- Max Charge Current (A): 100.
- Max Discharge Current (A): 108.
- Pulse/Peak Current (<3s): 216.
- Cycles @ 100% DoD: 2000.
- Cycles @ 80% DoD: 3000.
- Cycles @ 50% DoD: 5000.
- Cycles @ 30% DoD: 8000.
- Terminal Type: M8.
Important: All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. BMS Distributors will not be held liable for any product malfunctions as a result of incorrectly installed systems.SKU: n/a -
Batteries
BlueNova BN13V-108-1.4k MPS LiFePO4 Battery
Product Features
- Ultra-safe Lithium Iron Phosphate (LiFePO4) technology.
- Integrated battery management System (BMS).
- Light weight & compact.
- Water & dust resistant (IP56).
- Highly durable ABS enclosure.
- Drop in lead acid replacement in terms of physical size. Please ensure that your charge controller/ inverter are lithium compatible.
Technical Specifications
General- Battery Type: LiFePO4 (Lithium Iron Phosphate).
- Usable Capacity: 1400 Wh @C10, 25°C.
- Nominal Voltage: 13 VDC.
- Operating Voltage Range: 11.6 VDC – 14.4 VDC.
- Operating Temperature Range: Charge: 0°C – 45°C | Discharge: -20°C – 65°C.
- Cycle Life @ 100% DoD > 2000 cycles (1400 Wh @C10, 25°C).
- Cycle Life @ 80% DoD > 3000 cycles (1120 Wh @C10, 25°C).
- Cycle Life @ 50% DoD > 5000 cycles (700 Wh @C10, 25°C).
- Dimensions (mm): 342 x 173 x 220mm (W x D x H).
- Weight (kg) 16 kg.
- Warranty Period: 3 Years.
Charge / Discharge
- Bulk Voltage: 14.4 VDC.
- Discharge Voltage (min.): 11.6 V.
- Charge Current (max.): 52.5 A continuous.
- Discharge Current (max.): 110 A continuous; 160 A burst (30 seconds).
- Self-discharge Rate: < 3% per month.
- Charge & Discharge Efficiency: 96% – 99% @C1.
Protection
- Environmental Protection: IP56.
- Over-current Protection: 110 A.
- Over-voltage Cut-out: 15.6 V.
- Under-voltage Cut-out: 10.0 V.
Important: All solar products, power systems, water heating and gas products and their components must be installed by appropriately qualified personnel. All installations must adhere to local wiring regulations and standards. BMS Distributors will not be held liable for any product malfunctions as a result of incorrectly installed systems.SKU: n/a -
Inverters
RS485 / CAN Hub with 8 ports by Growatt
email: sales@bmsdistributors.co.za
Out of Stock !! Expecting Stock arrival. Orders can be placed in advance !!
This is a listing for RS485 / CAN Hub with 8 ports by Growatt
This product is used for connecting 1 battery bank and up to 7 Growatt inverters or charge controllers.
Whatsapp: +27 69 367 0341
SKU: n/a -
Panels
295 watt Solar Panel
- Eligible For Cash On Delivery – Pay our driver on delivery
- Free Delivery available for Cape Town customers
- Shipping : From R150.00
- email: sales@bmsdistributors.co.za
Description
- Solar Panel PV 395w
- dimensions : 580x360x25mm
- open circuit voltage : 21.0v
- short circuit current : 1.02A
- maximum power: 30w
- maximum power voltage :17.6v
- maximum current :1.7A
- maximum system voltage: 1000v (dc)
- module application : class A
- sealed junction box ,protect against external elements
- tempers low iron glass
- heavy duty frame
SKU: n/a -
-
Panels
250 watt Solar Panel
- Eligible For Cash On Delivery – Pay our driver on delivery
- Free Delivery available for Cape Town customers
- Shipping : From R150.00
- email: sales@bmsdistributors.co.za
Description
High Efficiency Solar Panel to give you the natural power that you need. A Versatile panel that has all the features to suit your environmentally friendly footprint for the future. This panel can be used in many applications from powering your house when the power grid is off to giving you power in the middle of nowhere on your adventures.
- Solar Panel PV 240w
- dimensions : 580x360x25mm
- open circuit voltage : 21.0v
- short circuit current : 1.02A
- maximum power: 30w
- maximum power voltage :17.6v
- maximum current :1.7A
- maximum system voltage: 1000v (dc)
- module application : class A
- sealed junction box ,protect against external elements
- tempers low iron glass
- heavy duty frame
- WDA60
SKU: n/a -
Panels
200 watt Solar Panel
- Eligible For Cash On Delivery – Pay our driver on delivery
- Free Delivery available for Cape Town customers
- Shipping : From R150.00
- email: sales@bmsdistributors.co.za
Quick Specs:
- Rating: 200W
- Efficiency: 15.7%
- Width: 808mm
- Height: 1,580mm
72 Cell 125mm X 125mm Series, Monocrystalline Solar Panel
- Rigirous quality control meeting highest international standards
- High-transmissivity low-iron tempered glass, stong aluminium frame using UV-resistant silicon.
- Aesthetic appearance with excellent efficiency based on innovative photovoltaic technologies.
SKU: n/a -
Panels
180 watt Solar Panel
- Eligible For Cash On Delivery – Pay our driver on delivery
- Free Delivery available for Cape Town customers
- Shipping : From R150.00
- email: sales@bmsdistributors.co.za
Description
Rating: 180W
Efficiency: 14.5%
Width: 992mm
Height: 1,250mm
72 Cell Solar PanelRigorous quality control meeting highest international standards
High-transmission low-iron tempered glass, strong aluminium frame using UV-resistant silicon.
Aesthetic appearance with excellent efficiency based on innovative photovoltaic technologies.
What’s in the box
1x 180w Cinco Solar PanelSKU: n/a -
Panels
150 watt Solar Panel
- Eligible For Cash On Delivery – Pay our driver on delivery
- Free Delivery available for Cape Town customers
- Shipping : From R150.00
- email: sales@bmsdistributors.co.za
Description
- High Efficiency Solar Panel to give you the natural power that you need. A Versatile panel that has all the features to suit your environmentally friendly footprint for the future. This panel can be used in many applications from powering your house when the power grid is off to giving you power in the middle of nowhere on your adventures.
Product Features :
High Efficiency Conversion Modules
Robust waterproof design and strong aluminium frame for all weather conditions
Fitted with a blocking diode to make sure there is no reverse current flow from the battery at night
Corrosion-resistant aluminum frame for extended outdoor use, allowing the panels to last for decades
Easy to install and angle adjustable bracketPanel specifications:
Maximum power: 150W
Open circuit voltage: 21.6V
Short-circuit current: 9.72A
Maximum power voltage: 18V
Maximum power current: 8.72A
Maximum system voltage: DC1000V
Nominal operating temperature: 45 – 85°C
Operating temperature: -40 – 85°C
Dimensions [l x w x h]: 1490 x 670 x 35cm
Weight: 15.2kgWhat’s in the box
1 X 150W Solar Panel
SKU: n/a -
Panels
120 watt Solar Panel
- Eligible For Cash On Delivery – Pay our driver on delivery
- Free Delivery available for Cape Town customers
- Shipping : From R150.00
- email: sales@bmsdistributors.co.za
Description
This 120w solar panel is powerful enough to keep your battery charged over long periods away without starting the generator or plugging in to an external source. Comes with MC4 connectors so they are easily added to a string and protected from the wet weather. MCS certified, fully weather proof and professionally made with high quality components. You will require a charge controller to regulate the flow of energy into the battery.
Specification:
Panel Size 670mm(w) x 1020mm(h) x 35mm(d)
Weight 10kg
Peak Power: 120w
Open Circuit Voltage: 12V
Short Circuit Current: 5.45A
Power Allowance Range: 3%
Max Power Voltage: 12V
Max Power Current: 5.45A
Max System Voltage: 1000VDC
Number of Cells: 44What’s in the box
1x120W Solar panelSKU: n/a -
Other
100 Watt Solar Panel
- Eligible For Cash On Delivery – Pay our driver on delivery
- Free Delivery available for Cape Town customers
- Shipping : From R150.00
- email: sales@bmsdistributors.co.za
Description
High Efficiency Solar Panel to give you the natural power that you need. A Versatile panel that has all the features to suit your environmentally friendly footprint for the future. This panel can be used in many applications from powering your house when the power grid is off to giving you power in the middle of nowhere on your adventures.
Product Features :
High Efficiency Conversion Modules
Robust waterproof design and strong aluminium frame for all weather conditions
Fitted with a blocking diode to make sure there is no reverse current flow from the battery at night
Corrosion-resistant aluminum frame for extended outdoor use, allowing the panels to last for decades
Easy to install and angle adjustable bracketPanel specifications:
Maximum power: 100W
Open circuit voltage: 23.15V
Short-circuit current: 5.45A
Maximum power voltage: 18V
Maximum power current: 5.12A
Maximum system voltage: DC1000V
Nominal operating temperature: 45 – 85°C
Operating temperature: -40 – 85°C
Dimensions [l x w x h]: 1055 x 670 x 35cm
Weight: 8kgSKU: n/a -
Inverters
KODAK Solar Off-Grid Inverter King with UPS 5kW 48V (OG-PLUS5.48)
*** Alternative Payment Method for Cape Town Customers ***
- Cash on Delivery – This will be paid to our Driver on delivery
email: sales@bmsdistributors.co.za
whatsapp: +27 69 367 0341
Product Description:
Shipment is not included for None Cape Town Customers.
In rural or end-of-line locations, the AC grid voltage can fluctuate across a wide range. Voltage that is sufficently far from the nominal 230V can cause applicances to run much less efficiently, or make them unable to function.
Most other inverters that are capable of running in Island Mode simply pass through the variable grid voltage and only produce a smooth 230V supply in the event of a grid failure.
Kodak’s King Off-Grid inverter is perfect for areas where grid electricity is less stable because it produces smooth 230V AC at all times, whether the grid is available or not.
This is great for efficient running of applicances, but crucial for an uninterrupted supply for important loads such as servers or ATMs.
- Built-in Bluetooth for mobile monitoring Detachable LCD control module with multiple communications (Android App is available)
- Supports USB On-the-Go function
- Reserved communication port for BMS (RS485)
- Parallel operation up to 9 units
- Robust UPS (uninterrupted power supply) for essential loads with zero transfer time
SKU: n/a -
Inverters
KODAK Solar Off-Grid Inverter VMIII 5kW 48V OG 5.48
*** Alternative Payment Method for Cape Town Customers ***
- Cash on Delivery – This will be paid to our Driver on delivery
email: sales@bmsdistributors.co.za
whatsapp: +27 69 367 0341
Product Description:
Shipment is not included for None Cape Town Customers.
- The OG 5.48 is ideal as an affordable and fully functional centre of your off-grid system. The wide MPP voltage range makes DC string design with your choice of module easy. It’s best suited to smaller domestic systems where no parallel operation is needed.Removable LCD control module with multiple communications servers and ATM
- Built-in Bluetooth for mobile monitoring (Android App is available)
- Replaceable fan design for ease of maintenance Supply load from Grid or PV, even battery is not available
- Configurable AC/PV output usage timer and prioritization Selectable high power charging current
- Selectable input voltage range for home appliances and personal computers
- Compatible to Utility Mains or generator input Auto restart while AC is recovering Cold start function
- 3 year warranty
Note: The Kodak VMIII inverter has a RS485 port that can be connected to the RS485 port on the Pylontech batteries for BMS communication. Therefore no other control module, such as the ICC, is needed.
SKU: n/a -
Inverters
KOOL Energy Solar Inverter 2200W
*** Alternative Payment Method for Cape Town Customers ***
- Cash on Delivery – This will be paid to our Driver on delivery
Whatsapp Contact No: 069 367 0341
Product Description:
Shipment is not included for None Cape Town Customers.
Input
– Voltage: 230VAC
– Selectable Voltage Range: 170VAC-280VAC (Personal Computers)
– Selectable Voltage Range: 90VAC-280VAC (Home Appliances)
– Frequency Range: 50Hz/60Hz (Auto Sensing)Output
– Rated Power: 2200W
– AC Voltage Regulation (Battery Mode): 230VAC ±5%
– Surge Power: 4000VA
– Efficiency: 90% to 93%
– Transfer Time: 10ms (Personal Computers) / 20ms (Home Appliances)
– Waveform: Pure Sine WaveSolar Charger & AC Charger
– Maximum PV Array Power: 1400W
– MPPT Range (Operating Voltage): 30VDC-80VDC
– Maximum Solar Charge Current: 50A
– Maximum AC Charge Current: 20AEnvironment Limit
– Humidity: 5% to 95% (Non Condensing)
– Operating Temperature Range: -10°C to +50°C
– Storage Temperature: -15°C to +60°C
– Communication: USB/RS232What’s in the box
1 x Kool Energy 2.2kW Off Grid InverterSKU: n/a
